ECH-U1H101JX5 Panasonic Electronic Components PCF1316CT-ND
| TYPE | DESCRIPTION | SELECT ALL |
| Categories | Capacitors | |
|---|---|---|
| Film Capacitors | ||
| Manufacturer | Panasonic Electronic Components | |
| Series | ECH-U(X) | |
| Packaging | Cut Tape (CT) | |
| Part Status | Active | |
| Capacitance | 100pF | |
| Tolerance | ±5% | |
| Voltage Rating - AC | - | |
| Voltage Rating - DC | 50V | |
| Dielectric Material | Polyphenylene Sulfide (PPS), Metallized - Stacked | |
| Operating Temperature | -55°C ~ 125°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 0805 (2012 Metric) | |
| Size / Dimension | 0.079" L x 0.049" W (2.00mm x 1.25mm) | |
| Height - Seated (Max) | 0.043" (1.10mm) | |
| Termination | Solder Pads | |
| Lead Spacing | - | |
| Applications | General Purpose |
