Molex 0436500512
Product Attributes
|
Type |
Description |
Select All |
|---|---|---|
|
Category |
Connectors, Interconnects Rectangular Connectors Headers, Male Pins |
|
|
Mfr |
Molex |
|
|
Series |
Micro-Fit 3.0 43650 |
|
|
Packaging |
Tape & Reel (TR) Cut Tape (CT) Digi-Reel® |
|
|
Part Status |
Active |
|
|
Connector Type |
Header |
|
|
Contact Type |
Male Pin |
|
|
Pitch - Mating |
0.118" (3.00mm) |
|
|
Number of Positions |
5 |
|
|
Number of Rows |
1 |
|
|
Row Spacing - Mating |
- |
|
|
Number of Positions Loaded |
All |
|
|
Style |
Board to Cable/Wire |
|
|
Shrouding |
Shrouded - 4 Wall |
|
|
Mounting Type |
Surface Mount, Right Angle |
|
|
Termination |
Solder |
|
|
Fastening Type |
Locking Ramp |
|
|
Contact Length - Mating |
- |
|
|
Contact Length - Post |
- |
|
|
Overall Contact Length |
- |
|
|
Insulation Height |
0.172" (4.37mm) |
|
|
Contact Shape |
Square |
|
|
Contact Finish - Mating |
Tin |
|
|
Contact Finish Thickness - Mating |
60.0µin (1.52µm) |
|
|
Contact Finish - Post |
Tin |
|
|
Contact Material |
Brass |
|
|
Insulation Material |
Liquid Crystal Polymer (LCP), Glass Filled |
|
|
Features |
Solder Retention |
|
|
Operating Temperature |
- |
|
|
Ingress Protection |
- |
|
|
Material Flammability Rating |
UL94 V-0 |
|
|
Insulation Color |
Black |
|
|
Current Rating (Amps) |
- |
|
|
Voltage Rating |
- |
|
|
Mated Stacking Heights |
- |
|
|
Contact Finish Thickness - Post |
- |
|
|
Applications |
General Purpose, Medical, Military, Telecommunications |
|
|
Base Product Number |
043650 |
